For EPC procurement teams, the drawing package is the foundation of a steel structure RFQ. If the package only includes a layout image or an early concept plan, suppliers may quote based on different assumptions. That makes prices hard to compare and increases the risk of later variation claims.
Detailed answer
Steel structure quotation drawings should give the fabricator enough information to understand scope, tonnage assumptions, connection intent, material and coating requirements, and delivery basis before pricing starts. EPC buyers should normally provide general arrangement drawings, structural or member schedule information, typical connection details, design loads or code basis, scope boundaries, and a drawing transmittal that shows revision status. If any part of the package is still preliminary, the RFQ should clearly separate confirmed information from provisional assumptions so quotations can still be compared fairly.
1. General arrangement drawings
General arrangement drawings show the building layout, grid lines, elevations, spans, bay spacing, eave height, ridge height, floor levels, and major structural zones. They help the supplier understand the project scale and the relationship between columns, beams, roof framing, mezzanines, crane beams, and envelope interfaces.
- Plan view with grid dimensions.
- Elevation views and roof slope.
- Building length, width, height, and bay spacing.
- Crane, platform, mezzanine, or special equipment zones.
2. Structural drawings and member schedules
Structural drawings allow the fabricator to understand steel member types, section sizes, connection locations, and estimated tonnage. If fabrication drawings are not ready, provide at least structural design drawings or a member schedule that states columns, beams, bracing, purlins, girts, and secondary steel.
| Drawing item | Why it matters |
|---|---|
| Column and beam layout | Defines primary steel quantity and fabrication complexity. |
| Connection details | Helps estimate plates, bolts, welding, drilling, and shop labor. |
| Purlin and girt layout | Clarifies secondary steel quantity and package scope. |
| Bracing layout | Shows stability system and site assembly requirements. |
3. Load and design basis information
Suppliers cannot safely confirm scope if the design basis is unclear. EPC buyers should identify the design code, wind load, snow load, seismic requirement, crane load, live load, and any project-specific owner standard. This is especially important when quotations are requested before final design approval.
4. Material, welding, and coating notes
The quotation should state material grades, bolt grades, welding standard, surface preparation grade, paint system, dry film thickness, galvanizing requirement, and color requirement. Missing coating notes often create large differences between quotes.
5. Interface drawings
Steel structure packages often connect with cladding, equipment foundations, conveyors, pipe racks, crane systems, doors, louvers, or civil works. If these interfaces are not shown, ask suppliers to list exclusions clearly instead of hiding assumptions in the price.
6. Minimum drawing package before quotation
- General arrangement drawings.
- Structural design drawings or member schedule.
- Connection intent or typical connection details.
- Material and coating specifications.
- Design code and load information.
- Scope boundary and exclusions.
- Destination country and delivery basis.
7. RFQ drawing transmittal table
A steel structure RFQ drawing package should be issued with a simple transmittal table. This helps every bidder confirm they priced the same revision, the same scope boundary, and the same missing-information list.
| Transmittal field | What EPC buyers should record |
|---|---|
| Drawing number and title | List each general arrangement, section, elevation, connection, and specification sheet separately. |
| Revision and issue date | Show the latest revision so bidders do not price superseded drawings. |
| Quotation status | Mark whether the drawing is approved, for tender, preliminary, or for reference only. |
| Pricing instruction | State whether bidders should include the item as firm scope, provisional scope, optional scope, or excluded scope. |
| Open questions | Record missing loads, unclear dimensions, coating gaps, connection assumptions, or delivery limits. |
8. What to do when quotation drawings are incomplete
Many EPC teams request steel structure quotation drawings before final design release. That is workable if the RFQ separates confirmed information from assumptions. Ask each bidder to identify the assumptions used for tonnage, connection plates, bolts, coating, packing, and delivery. Do not compare only the total price when one bidder has included provisional items and another has excluded them.
When the drawing package is still incomplete, compare supplier assumptions with a basic steel structure production capacity checklist so buyers can judge whether the fabricator can realistically support the proposed tonnage and delivery window.
- Ask for a priced deviation list instead of allowing hidden assumptions.
- Request a separate provisional allowance for unclear members, secondary steel, or coating systems.
- Keep connection design responsibility clear if final connection drawings are not available.
- Confirm whether the price includes drawing detailing, material substitution review, and shop drawing revision work.
- Require bidders to state which drawings were used for the quotation.
9. Drawing questions to ask before comparing quotes
Before awarding a steel structure package, compare the drawing basis behind each quote. This is often more useful than asking for a lower price, because it reveals whether the suppliers priced the same work.
| Buyer question | Why it protects the quotation |
|---|---|
| Which drawing revision did you price? | Prevents a bidder from using an older or incomplete issue. |
| Which members are excluded? | Separates primary steel, secondary steel, stairs, platforms, handrails, and embedded items. |
| Which connection details are assumed? | Clarifies plate thickness, bolt quantity, hole type, welding length, and site assembly method. |
| Which coating specification is included? | Prevents major price gaps caused by different surface preparation or paint systems. |
| Which documents will be submitted after award? | Confirms shop drawings, material certificates, inspection records, packing lists, and shipping documents. |
Frequently asked questions
What drawings are needed for a steel structure quotation?
EPC buyers should provide general arrangement drawings, structural design drawings or member schedules, typical connection details, material and coating specifications, design loads, scope boundaries, and the delivery basis.
Can a steel structure quote be requested before final drawings are approved?
Yes, but the RFQ should separate confirmed information from assumptions. Ask bidders to list provisional items, excluded items, assumed connection details, coating assumptions, and any pricing limits caused by incomplete drawings.
Why should drawing revisions be listed in the RFQ transmittal?
A drawing transmittal helps every bidder price the same revision and scope. It reduces disputes caused by old drawings, missing sheets, unclear status, or different assumptions between bidders.
Buyer note
If the drawings are still preliminary, say so in the RFQ. Ask each supplier to separate firm pricing from provisional items. This makes the quotation easier to compare and reduces disputes after award.
Buyer follow-up questions
How should buyers use this page?
Use it as a practical review aid for steel structure quotation drawings epc buyers need. The page helps the buyer confirm what must be checked, what evidence should be requested, and which follow-up actions should be closed before the package moves to the next procurement step.
When should this review happen?
Use it before issuing an RFQ or when quotations are difficult to compare because drawings, scope, or assumptions are unclear.
What evidence should be kept?
Keep the records that prove the decision, especially drawings, revision status, scope boundaries, material and coating standards, destination data, schedule assumptions, and supplier exclusions. Photos, comments, approvals, open issues, and closeout notes should stay linked to the relevant drawing, supplier reply, shipment, or handover record.
